Tenda O3 User Manual

139
Parameters description
Name
Description
IP Address of Peer AP
It specifies the LAN IP address of peer CPE. You can enter it manually or select an IP
address from the drop-down list if there are devices connected to the CPE.
IP Address
If the IP Address of Peer AP is set to Manual, you need to enter the LAN IP address
of peer CPE in the box manually.
HTTP Port
It specifies the HTTP service port number of peer device, which is used to establish
speed test connection based on TCP/IP. Default: 80. You are recommended to keep
the default value.
User Name
It specifies the login user name and password of peer device.
Password
Test Group
It specifies the number of test connection launched.
Direction
It specifies the test speed direction.

RX (Receive): only test the speed that the peer device transmits data to this

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
