Tenda O3 User Manual

157
The registered domain name information is shown as follows:
− Service Provider: Dyndns
− User Name: tenda
− Password: tenda
− Domain Name: tenda.dyndns.com
Network topology
Configuration procedures
Step 1 Set up the DDNS function.
1. Start a web browser on the computer connected to the CPE, visit 192.168.2.1 and choose
Advanced > Network Service.
2. Enable the DDNS function.
3. Select a service provider, which is Dyndns in this example.
4. Enter the user name and password you registered with DDNS service provider, which are
tenda and tenda in this example.
5. Enter the domain name you registered, which is tenda.dyndns.com.
6. Click Save on the bottom of this page.
Web Server
CPE: WISP mode
Computer1
Computer2
ISP Hotspot
Switch

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
