Tenda O3 User Manual

158
Step 2 Set up the port forwarding function.
Prerequisite: manually set static an IP address and related parameters for the web server to avoid
the service disconnection caused by the dynamic IP address.
1. Start a web browser on the computer connected to the CPE, visit 192.168.2.1 and choose
Advanced > Port Forwarding.
2. Enter the IP address of the web server, which is 192.168.2.100 in this example.
3. Select an application, which is HTTP in this example, and the Internal Port and External Port
will be populated automatically.
4. Select the protocol of the service. TCP&UDP is recommended if you are not sure.
5. Click Add.
----End

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
