Tenda O3 User Manual

iii
Acronyms and Abbreviations
Acronym or Abbreviation
Full Spelling
AP
Access Point
ARP
Address Resolution Protocol
AES
Advanced Encryption Standard
CPE
Customer Premises Equipment
CCQ
Client Connection Quality
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name System
DDNS
Dynamic Domain Name Server
GMT
Greenwich Mean Time
IP
Internet Protocol
ICMP
Internet Control Message Protocol
LAN
Local Area Network
MAC
Media Access Control
PoE
Power over Ethernet
P2MP
Point-to-MultiPoint
PVID
Port-based VLAN ID
RADIUS
Remote Authentication Dial In User Service
SSID
Service Set Identifier
TCP
Transmission Control Protocol
TKIP
Temporal Key Integrity Protocol
UDP
User Datagram Protocol
VLAN
Virtual Local Area Network
WAN
Wide Area Network
WEP
Wired Equivalent Privacy
WLAN
Wireless Local Area Networks
WMM
Wi-Fi multi-media

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
