Tenda O3 User Manual

71
Parameters description
Name
Description
Working modes
It specifies the working mode of this device.
Router mode: In this mode, the PoE/LAN port works as the WAN port and is used to
connect to a modem for internet access.
Internet Connection
Type
The device in Router mode supports three internet connection types:

DHCP (Dynamic IP): The device obtains the IP address and other parameters from the
DHCP server of upstream device for internet access.

Static IP Address: The device accesses the internet using the IP address, subnet mask,
default gateway and DNS server IP addresses provided by your ISP.

PPPoE: The device accesses the internet using the PPPoE user name and password
provided by the ISP.
SSID
It specifies the wireless network name of the device.
Channel
It specifies the channel that the WiFi network operates.
Security Mode
It specifies the security mode of the WiFi network of the device. It includes None,
WPA-PSK, WPA2-PSK, and Mixed WPA/WPA2-PSK.
Clicking the hyperlink navigates you to the elaborated description of the corresponding
security mode.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
