Manage Your Adapters
13
In the Device List, you can view the adapters in a same powerline network which have negotiated
with each other.
CCO
This adapter will be regarded as a station, to which other adapters will attempt to connect.
When attempting to connect to each other, adapters automatically negotiate with each other to
select an adapter as CCO.
Local
This adapter is connected to the computer with the UI installed.
Device Info
The Device Info of a currently selected adapter.
Network name
/HomePlugAV
HomePlugAV is the local Powerline network name if you do not customize a Powerline
network name, or use pair button to pair the adapters with each other. To establish a same
powerline network, powerline adapters MUST share an identical network name. Based on the
network name, the powerline network is classified into 2 types: a powerline network named
“HomePlugAV” is considered a public network; a powerline network named “Private” is
considered an encrypted network.
MAC Address
The MAC address of a currently selected adapter.
Click to see the User Guide.
3 Change Device Name
For easy recognition and convenient management, you can change the adapter’s name if there are
multiple adapters managed by the UI.
To change device name:
 Click to start configuration.
 Select Change Device Name.

Tenda PH3 AV1000 Specifications

General

Model	PH3
Type	Powerline Adapter
Data Transfer Rate	1000 Mbps
Encryption	128-bit AES
Button	Pair Button
Modulation Technology	OFDM
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Technology	HomePlug AV2
Operating Voltage	100-240V AC
Operating Frequency	50/60Hz
Plug Type	EU, UK, US
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Power, Ethernet
Input	AC 100-240V~50/60Hz 0.1A
Frequency Band	2-68MHz
System Requirements	Windows, Mac, Linux
Package Content	2 x Ethernet cables, Quick Installation Guide
Ports	1 x RJ45
Interface	Gigabit Ethernet Port
