Tenda PH3 AV1000 User Manual

Manage Your Adapters
15
After it saved successfully, you’ll find that the Device name displays the new name.
4 Change Network Name
To establish a same powerline network, powerline adapters MUST share an identical network name.
Therefore, if you change one adapter’s network name in a powerline network, you MUST change
the other adapters’ as well. If not, the adapter will exit from the current powerline network. Also, if
you change the default network name HomePlugAV into another one, this powerline network will
become an encrypted private powerline network. You need to use the pair button to add more
adapters into this powerline network.
To change the network name:
 Click to start configuration.
 Then select Change Network Name.

Tenda PH3 AV1000 Specifications

General

Model	PH3
Type	Powerline Adapter
Data Transfer Rate	1000 Mbps
Encryption	128-bit AES
Button	Pair Button
Modulation Technology	OFDM
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Technology	HomePlug AV2
Operating Voltage	100-240V AC
Operating Frequency	50/60Hz
Plug Type	EU, UK, US
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Power, Ethernet
Input	AC 100-240V~50/60Hz 0.1A
Frequency Band	2-68MHz
System Requirements	Windows, Mac, Linux
Package Content	2 x Ethernet cables, Quick Installation Guide
Ports	1 x RJ45
Interface	Gigabit Ethernet Port
