Tenda PH3 AV1000 User Manual

Access the Internet
4
 Connect the other adapter to a computer or other wired devices, and plug it to a wall outlet.
 Wait until the PLC LEDs on the two adapters are lit.
Then you can try accessing the Internet via your computer. If you cannot access the Internet
after the operation above, please refer to Q1 for solution.
2 Secure Your Powerline Network
Two or more powerline adapters under the same electrical circuit will automatically interconnect to
create an unencrypted public network (Named “HomePlugAV”).
If you want to create a secure powerline network (Named “Private”), use the Pair button to pair the
two adapters with each other.

Tenda PH3 AV1000 Specifications

General

Model	PH3
Type	Powerline Adapter
Data Transfer Rate	1000 Mbps
Encryption	128-bit AES
Button	Pair Button
Modulation Technology	OFDM
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Technology	HomePlug AV2
Operating Voltage	100-240V AC
Operating Frequency	50/60Hz
Plug Type	EU, UK, US
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Power, Ethernet
Input	AC 100-240V~50/60Hz 0.1A
Frequency Band	2-68MHz
System Requirements	Windows, Mac, Linux
Package Content	2 x Ethernet cables, Quick Installation Guide
Ports	1 x RJ45
Interface	Gigabit Ethernet Port
