Tenda PH3 AV1000 User Manual

Contents
1
I Get to Know the Adapter
Before you use the PLC product, take a moment to become familiar with the package contents and
the front panel. Pay particular attention to the LEDs on the front panel.
1 Overview
PH3 AV1000 Gigabit Powerline Adapters are designed for online video/audio player, web camera,
IPTV and other high bandwidth applications. It adopts electrical circuit to transmit Internet data
with electrical power, which in a sense reduces the Ethernet cable cost and easily extends network
coverage to where the electrical power can get within the valid range. The rate of these powerline
adapters are up to 1000Mbps, giving a guarantee of a more fluent online playing experience.
2 Package Contents
Unpack the package. Your box should contain the following items:
 AV1000 Gigabit Powerline Adapter * 2
 Install Guide * 1
 Ethernet Cable * 2
* If any item is incorrect, missing or damaged, please keep the original package and contact the
vendor for replacement immediately.

Tenda PH3 AV1000 Specifications

General

Model	PH3
Type	Powerline Adapter
Data Transfer Rate	1000 Mbps
Encryption	128-bit AES
Button	Pair Button
Modulation Technology	OFDM
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Technology	HomePlug AV2
Operating Voltage	100-240V AC
Operating Frequency	50/60Hz
Plug Type	EU, UK, US
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Power, Ethernet
Input	AC 100-240V~50/60Hz 0.1A
Frequency Band	2-68MHz
System Requirements	Windows, Mac, Linux
Package Content	2 x Ethernet cables, Quick Installation Guide
Ports	1 x RJ45
Interface	Gigabit Ethernet Port
