Tenda PH3 AV1000 User Manual

Access the Internet
6
3 Add Adapters to a Private Powerline
Network
If you want to add more powerline adapters to a private powerline network, follow the steps below:
 Press the Pair button on any powerline adapter in the security powerline network for 1 second.
 Within two minutes, plug in the new powerline adapter, and press its Pair button for 1 second.
 Observe the PLC LEDs on the two adapters until they are lit.
 Done.

Tenda PH3 AV1000 Specifications

General

Model	PH3
Type	Powerline Adapter
Data Transfer Rate	1000 Mbps
Encryption	128-bit AES
Button	Pair Button
Modulation Technology	OFDM
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Technology	HomePlug AV2
Operating Voltage	100-240V AC
Operating Frequency	50/60Hz
Plug Type	EU, UK, US
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Power, Ethernet
Input	AC 100-240V~50/60Hz 0.1A
Frequency Band	2-68MHz
System Requirements	Windows, Mac, Linux
Package Content	2 x Ethernet cables, Quick Installation Guide
Ports	1 x RJ45
Interface	Gigabit Ethernet Port
