300M Wireless-N Access Point
802.1x Authentication
Thi
s security mode is used when a RADIUS server
is connected to the device. 802.1x, a kind of
Port-based authentication protocol, is an
authentication type and strategy for users. The
port can be either a physic port or logic port (such
as VLAN). For wireless LAN users, a port is just a
channel. The final purpose of 802.11x
authentication is to check if the port can be used.
If the port is authenticated successfully, you can
open this port which allows all the messages to
pass. If the port isn’t authenticated successfully,
you can keep this port “disable” which just allows
802.1x authentication protocol message to pass.
Select “802.1x” from the drop-down menu to
enter the following window:
31
