Tenda W308R User Manual

11N Wireless Broadband Router User Guide
28
4.3 LAN Settings
Click “Advanced settings” –LAN settings to enter the
following screen.
¾ LAN MAC address: The Router’s LAN MAC address,
which is unchangeable.
¾ IP address: The Router’s LAN IP address (not your
PC’s IP address).The default value is 192.168.0.1;
you can change it when necessary.
¾ Subnet mask: The Router’s LAN subnet mask. The
default value is 255.255.255.0
NOTE:
Once you modify the IP address, you need to remember
it for next time you log in to the web-based utility.

Tenda W308R Specifications

General

Wireless Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
Antenna	2 x 5dBi external antennas
LAN Ports	4x 10/100 Mbps
WAN Ports	1x 10/100 Mbps
Security	WPA, WPA2
WAN Connection Type	Dynamic IP, Static IP, PPPoE
