Pulse Width Trigger
Pulse width trigger means determining the triggering time based on the
trigger width. You can acquire abnormal pulse by setting the pulse width
condition.
Table 2-7(P.1)
Function Menu Setup
Explanatory Note
Type Pulse
Set CH1 as the signal source trigger signal
Set CH2 as the signal source trigger signal
Set the external trigger input channel as the signal source trigger signal
Set up as grid trigger
CH1, CH2 trigger signals alternately
C H1
CH2
EXT
AC Line
Alter
Source
When
＞
＜
＝
Trigger when pulse width is larger than default value
Trigger when pulse width is smaller than default value
Trigger when pulse width equals to default value
Set the pulse width at 20ns~10s and adjust by turning the multifunction
control knob on the upper front panel
20ns ~ 10s Setting
Next ½
Move to next page
39
DSO Series User Manual
To Next Page
