Appendix A : Technical Indicators
Unless otherwise specified, all technical specifications apply to probes
with attenuation setting of 10X and the DSO Series Digital
Oscilloscope. To verify that your oscilloscope meets specifications, it
must first meet the following conditions :
n The oscilloscope must have been operating continuously for
thirty minutes at the specified operating temperature.
n If the operating temperature changes by more than 5°C, you
must perform the “Self Cal” operation, accessible through
the system functions menu. All specifications are guaranteed
unless noted “Typical”.
81
Sampling
Sampling modes
Real time sampling
Equivalent sampling
Bandwidth
Sampling
Average value
72-8710
72-8705
1GS/s
100MHz 50MHz
Sampling, peak detect, average
When all channels have made N samplings
simultaneously, N is selectable from 2, 4, 8, 16,
32, 64, 128 to 256
50GS/s
Input
Input coupling
Input impedance
Probe attenuation factor
Maximum input voltage
Ti m e d e l a y b e t w e e n
channels (Typical)
DC, AC, GND
1MΩ ± 2% in parallel with 20 ± 3pF
400V (DC + AC Peak, 1MΩ input
impedance)
150ps
1 , 10×, 100×, 1000××
