RUN/STOP : Acquire waveform continuously or stop acquisition.
If you want the oscilloscope to acquire waveform continuously, press
[RUN/STOP] once. Press the button again to stop acquisition. You can
use this button to switch between acquiring and stop acquiring
waveform. In the Run mode, a green light comes on and AUTO appears
on the screen. In the STOP mode, a red light comes on and STOP
appears on the screen.
Function Menu Setup
Sampling
SEC/DIV
Table 2-32
Horizontal position
Set to YT
Display format
Automatic adjustment
AC
Acquisition mode
Adjust according to signal frequency
Trigger coupling
Minimum value
Holdoff
Auto
Trigger mode
Trigger level
Set at 50%
Rising
Trigger inclination
Set to CH1 but if there is no signal in
CH1 and CH2 applies a signal, it will
set to CH2
Trigger source
Full
Vertical bandwidth
Trigger type
Edge
Adjust according to amplitude of the
signal
VOLT/DIV
62
DSO Series User Manual
