BOLT 4K ARRAY PANEL ANTENNA
A: RP-SMA connectors (vertical)
B: RP-SMA connectors (horizontal)
C: Battery plate
D: Yoke assembly
E: 3/8” Light stand adapter
C
B
B
A
D
3
E
ANTENNA CONFIGURATION
The Array Panel Antenna has both vertical (A) and horizontal (B) antenna connectors. The
transmitter's antenna configuration will determine which Array Panel RP-SMA connectors you
use with the receiver. For more information, go to Vertical and Horizontal Antennas on page 8.
