Terberg OmniDEL User Manual

1.2 Technical specifications
Omni DEL e
5
ã Terberg Machines B.V. IJsselstein, The Netherlands
All rights reserved. No part of this book may be reproduced, stored in database or retrieval system, or published, in any form or in any way,
electronically, mechanically, by print, photoprint, microfilm or any other means without prior written permission from the publisher.
2-wheel bins
4-wheel containers
flat lid
4-wheel containers
roll top
Paladin
containers
Capacity 80 - 360 litres 500 - 1280 litres 770 and 1100 litres 900 litres
According to standard EN 840-1 EN 840-2 EN 840-3 --
Lifting capacity 1600N (160 kg) 5000N (500 kg)
Cycle time (excl. dwell time) 6.0 seconds 11 seconds
Time in tipping position Adjustable Adjustable
Guidelines and standards
2006/42/EG, EN 1501-1 & EN 1501-5:2011
Weight 595 kg (depending on configuration)
Noise levels ≤ 65 dB(A)
Vibrations ≤ 2.5 m/s
2
Operating voltage 24 Volts
Maximum current consumed by control 10 Amps
Oil flow 40-60 litres/minute
Working pressure PTO Min. 180 bar / Max. 250 bar
Return pressure Max. 2.0 bar
Quick release couplings DIN 25, ISO 72141-1
2-wheel bins
4-wheel containers
flat lid
Capacity 80 - 360 litres 500, 660 and 770 litres
According to standard EN 840-1 EN 840-2
Lifting capacity 1000N (100 kg) 3500N (350 kg)
Cycle time (excl. dwell time) 6.0 seconds 11 seconds
Time in tipping position Adjustable Adjustable
Guidelines and standards
2006/42/EG, EN 1501-1 & EN 1501-5:2011
Weight 655 kg (depending on configuration)
Noise levels ≤ 58 dB(A)
Vibrations ≤ 2.5 m/s
2
Operating voltage 24 Volts
Maximum current consumed by control 10 Amps
Average power consumption during normal daily use 20 Ah
Average electrical power 2-wheel bin 1.8 kW
Maximum electrical power 2-wheel bins (1000N) 3.6 kW
Maximum electrical power 4-wheel containers (5000N) 5.2 kW
Omni DEL
Bins/containers to be emptied, “teardrop” catcherbar
Bins/containers to be emptied, 2-position catcherbar / lid opener
The emptying of bin/container types other than
those indicated above, is not permitted with
this bin lift system. If in doubt, please contact
your distributor.
