Terex PT-100G Forestry - Hydraulic Control Circuit

Hydraulic Control Circuit
Figure 3-3 PT-100G Hydraulic Control Circuit
3-3
Compact Track Loader
3. Circuit Diagrams
LIFT ARM CONTROL VALVE
TO LIFT ARM CYL.
TO BUCKET CYL.
TO POWER Q/A.
TO
TANK
CHARGE PRESSURE
TEST PORT
(400 / 2758 kPa)
