Terex PT-100G Forestry - Hydraulic Drive Circuit

Hydraulic Drive Circuit
Figure 3-4 PT-100G Hydraulic Drive Circuit
3-4
Compact Track Loader
3. Circuit Diagrams
DRIVE MOTOR
DRIVE PUMP
CASE DRAIN
(TO COOLER)
BRAKE
2-SPEED SHIFT
DRIVE MOTOR
CHARGE PRESSURE
RELIEF
(400 / 2758 kPa)
DRIVE PRESSURE
RELIEF VALVES (4)
(5500 PSI / 37920 kPa)
