Chapter Overview
This chapter provides removal and installation proce-
dures for the quick attach and associated components.
Personal Safety
Improper or incomplete maintenance/repair of a Compact
Track Loader can be dangerous and may result in machine
damage, injury or death.
Do not attempt to perform any type of repair or maintenance
on a Compact Track Loader until you have read and fully
understood the information in this manual. Refer to the
Operation and Maintenance manual for instructions regard-
ing proper machine operation techniques before operating
any Compact Track Loader.
Prior to performing any type of service work on a Compact
Track Loader, read and understand Chapter 1 (Product
Safety) for personal safety information.
Machine Preparation
Accidental machine starting can cause injury or death to per-
sonnel working on a Compact Track Loader.
As a precaution, disconnect the battery cables from the bat-
tery terminals, tape the battery clamps and remove the key
from the ignition switch prior to per-forming any service work
on a Compact Track Loader.
Place a “Do Not Operate” tag prominently on the machine to
inform personnel that the machine is be-ing worked on.
Removal and Installation
Removal and installation procedures are provided for
the following quick attach components.
• Quick Attach locking Pin Assemblies
• Quick Attach Pivot Pins
Note: Procedures are provided for only those quick attach
components listed above. However, exploded parts diagrams
exist in the PT-100G Parts manual to serve as visual aids in
the assembly and disassembly of other system components.
Locking Pin Assembly
Removal
1. Rest the lift arms on an Terex approved jack stand
to provide clearance for quick attach disassembly.
(fig. 15-1)
15. Quick Attach
15-1
Required Tools
Combination/Open End/Socket Wrenches
Terex Approved Jack Stand (or equivalent)
15-1
Remove any attachment, lower or safely sup-
port the lift arms and make sure the hydraulic
oil is cool before removing any components or
lines. Hot or pressurized oil can cause personal injury.
