91
Operating Manual Crawler Excavator TC37
Care and Maintenance 7
Removing the battery
• Open the cabin floor.
• First disconnect the battery ground cable (-), then
the positive cable (+).
• Slacken the clamping bracket (64/1).
• Lift out the battery.
Installing the battery
• Place the battery into the machine.
• Secure with the clamping bracket.
• Connect first the positive battery cable, then the
ground cable.
• Close again the cabin floor.
Checking the lighting and warning equipment
• Check the function of the lighting equipment.
• Check the function of the indicator lamps.
• Check the function of the warning equipment.
Fig. 64 Battery
Machine damage
due to reverse of terminals.
• Ensure that the negative terminal is
connected to the negative pole (-) and the
positive terminal to the positive pole (+).
Attention
In winter, in particular, the battery charge
should be closely monitored.
