Terracom IPSM-2C20 - Call;Hang up

Configuration-Web Browser 45
© 2022 Enter your company name
Function
Message Play
Message Stop
Contact Out
Command (String)
Multi Function
Record
User Fault
DSP Element
Adjust
Music Play
Music Stop
Contact Output
Output: The relay contact output of IPSM/IPBX-2C20, it can be programmed to open or close the
contact to an external device.
Default: Set the default state (open or close) of logic relay outputs after the TERRA-SAP is powered.
4.4.6.1 Call/Hang Up
Call (Intercom/Paging)
Proceed intercom or paging call by using the connected contact inputs of IPSM/
IPBX-2C20 to a chosen TERRACOM device target when closing or activating the
logic switch .
Hang Up
Hang up the intercom and paging call by opening or inactivating the logic switch .
Security
If the [Security] option is enable, the caller cannot hang up the call during paging
unless the call receiver cancels the call itself.
