With SIP server
The audio streaming can be done using a SIP
Server. Go to "Machine > Setting > SIP" and
enter the settings of your SIP server.
Without SIP server
If you don’t have a SIP server, please follow
the settings as below,
o Firewall Traversal Mode: TERRA Net
o SIP Port: 5060
o RTP Port: 6912
3 Hardware Installation
3.1 IPSM-2C20/IPSM-2C20M
Front panel
Rear panel
Modules of IPSM-2C20 are equipped with 1 channel in 2 channels in 20W with 8 ohm loudspeaker, and
PoE+ power (If PoE+ is not available, 24VDC power adapter will supply higher power). With Power over
Ethernet (PoE+), both audio control and power can be flowed over the standard female RJ45 Ethernet
