44 SoundSystem SiXPack 5.1 +
!
S/PDIF to AES/EBU
_
+ 5 volt | \
SPDIF out: | +-| O-+
_ | |_/ |
diode ^ +-4,7 k-+ _ | _ |
10 u (+) | | | | \ | | \ | 100 n
O-----+-||-+--------+--+--IC--+--+-| O-+-| O-+-120 r-||-+----+-- 2
| | | | | | |_/ |_/ | |
| +-||-+ 100n _ 2,2k | 1 k |
75r ^ diode | | IC | | AES in
| | --- | --- |
--- --- | _ 220r
| | \ 100 n |
+--+---| O---+--120 r-||-+---+--- 3
Diode = 1N914 or 1N4148 | |_/ | |
| _ | 1 k +--- 1
| | \ | | |
IC = 74HC04 or CMOS 4049 +---| O---+ --- ---
|_/
Please note. We do not guarantee in any way the safety or the func-
tioning of this circuit. Nor can we give any technical support for its im-
plementation.
