4-2 Description of Display
RATIO
ZERO
AVG
ZERO
MINMAX
: Auto power off indication.
ZERO : Zero mode indication (
φ
=
φ
in
–
φ
d
)
ZERO RATIO : Zero – Ratio mode indication
[RATIO = (
φ
in
–
φ
d
)/ (
φ
R
–
φ
d
)]
RATIO : Ratio mode indication (RATIO =
φ
in
/
φ
R
)
RATIO ZERO : Ratio – Zero mode indication
[RATIO = (
φ
in
–
φ
d
)/
φ
R
]
D-H : Display data hold mode indication.
A-H : Display Auto data hold mode indication.
SET : Setting mode indication.
SET SORT 10% : Sort tolerance limits setting mode indication
(10% to 100%).
SET 1.100 lumen : Comparator High limit value setting
indication.
SET 0.900 lumen : Comparator LOW limit value setting
indication.
SET
INTV 

. 

 1 A-M : Auto datalogging interval time selection
mode indication (1, 2, 3, 4, 5, 6, 7, 8, 9, 10,
20, 30, 40, 50 seconds or 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 20, 30, 40, 50, 60 minutes).
