TESA-hite 400 / 700
LIST OF CONTENTS PAGE
1 Main features 4
2 Installation 5
2.1 Unpacking and setting up 5
2.2 Starting the instrument 6
2.3 Short instructions for use 7
3 Description of the components 10
3.1 Instrument base 10
3.2 Air-cushion base 10
3.3 Vertical column, measuring head and movement of the head 10
3.4 Power supply 11
3.5 Measuring system 11
3.6 Automatic measuring value correction 11
4 Measuring 12
4.1 Basic principles 12
4.2 Display and function keys 12
4.2.1 Definition of display symbols 13
4.3 Program functions 14
4.4 Probing procedure at the contact point 16
4.5 Establishing the probe constant for length measurements
with inversion of the probing direction 17
4.6 Measuring features with flat surfaces 18
4.7 Measuring features with cylindrical surfaces 18
4.8 MODE 1, Measuring lengths in one direction, without probe constant 19
4.9 MODE 2, Measuring lengths in two directions, with probe constant 20
4.10 Procedure for detecting the culmination point 21
4.11 MODE 3, continuous display 27
4.12 PRESET function 29
4.13 Measuring parallelism deviations 33
4.14 Measuring perpendicularity deviations 36
4.15 Use of the fine adjustment 39
5 Instrument configuration 39
6 Error messages 44
7 Maintenance 44
7.1 Cleaning 44
7.2 Charging the battery 45
8 Delivery programme 45
8.1 Optional accessories 46
9 Technical data 49
9.1 Description of the RS 232 interface 50
9.1.1 Monodirectional data transmission 50
9.1.2 Bidirectional data transmission 50
10 Warranty 50
11 Declaration of conformity 51
3
