TESA TESA-hite 700 - 1 MAIN FEATURES

TESA-hite 400 / 700
1 MAIN FEATURES
Cap cover 1
Housing 2
Fig. 1
Probe fixing arm 4
Probe 5
Guiding and
support faces 6
3-point cast-iron base 7
Switch for electric
pump 11
Knurled screw for the fine
adjustment 9
Handwheel for
displacement 8
Knurled screw for locking the
measuring-head
drive 10
Mounting pin 3
Control panel 12
4
