USER MANUAL
DS 300H Series � 3/3 � 30 kVA � UPS CONTROLLED UPS
18
Level 1
Level 2
Page
Level 3
Set month Page3
Set year Page3
Update time and date Page4
ENTER - EXIT
SERVİCE Operating hourmeter Page1
Maximum load Page1
ENTER Fault reset Page1
Fan maintenance hourmeter Page2
Batt.maintenance hourmeter Page2
General maintenance hourmeter Page2
Logout command Page3
ENTER - EXIT
PASSWORD
Getting service code Page1
Type service password Page1
Type user password Page1
ENTER - EXIT
ADJUST
(in English) Group adjustments Automatic settings
Inverter factory options Options list
Rectifier factory options Options list
Panel adjustments Options list
AC input adjustments AC input settings
AC Bypass adjustments AC bypass settings
AC output adjustments AC output settings
DC adjustments DC settings
Power adjustments Power settings
ENTER - EXIT
19
3.2.1 MEASUREMENTS menu
All mesasured values of the UPS can be monitored from this menu.
Use up and down buttons to move on submenu
MEASUREMENTS / INPUT (Level 2)
All rectifier input measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
INPUT
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vinp: 221/222/223 V Phase to neutral measured AC input voltages
Iinp: 000/000/000 A Measured RMS AC input phase currents
…………………………….. Current alarm messages
Up previous page ,down next page
MEASUREMENTS
/
INPUT
Page 2 (Level 3)
P-P L13 L21 L32 Page header
Vinp: 381/382/383 V Phase to phase measured AC input voltages
Finp: 49.6 Hz Measured rectifier input frequency
…………………………….. Current alarm messages
Up previous page ,down next page
MEASUREMENTS
/
INPUT
Page 3 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS / BYPASS (Level 2)
All by-pass input measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
BYPASS
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vbyp: 221/222/223 V Phase to neutral measured AC bypass input voltages
OK OK -- Bypass voltage status
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
BYPASS
Page 2(Level 3)
P-P L13 L21 L32 Page header
Vbyp: 381/382/383 V Phase to phase measured AC bypass input voltages
Fbyp: OK / 50.0 Hz Measured bypass input frequency
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
BYPASS
Page 3(Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
