Tescom DS360H - ALARM LOGS Menu; INFORMATION Menu

24
www.tescom-ups.gr
USER MANUAL
DS 300H Series � 3/3 � 30 kVA � UPS CONTROLLED UPS
22
3.2.2 ALARM LOGS MENU
Use this menu to see the alarm log records
ALARM
LOGS
Page 1
(
Level
2)
UPS LOG RECORD Page header
>001>081110 14:33:26 Event no ,date and time (left and right buttons move)
ENTER CLEAR LOG ENTER buton clears all log memory
…………………………….. Current alarm messages
Up upper line, down next line
ALARM
LOGS
Page 2
(
Level
2)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
3.2.3 INFORMATION MENU
Some usefull informations are located in this menu , use up and down buttons to move on submenu
INFORMATION MENU
Page 1
(
Level
2)
RS232 Comm: 1:-- 2-- RS232 activity indicator for com1 and com2
MAX Power: 60000 VA Maximum ups output power as VA
Nom:220/050 220/050 Nominal input, output voltage and frequency
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 2
(
Level
2)
Inv version: 00001 Inverter module firmware version
Pfc version:00001 PFC rectifier module firmware version
Lcd version:00001 Front panel modul firmware version
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 3
(
Level
2)
Model:CL360D Model name of the UPS
Protocol:TX301 Communication protocol version
Chassis nr: 123456 UPS chassis nr
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 4
(
Level
2)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
23
3.2.4 OPTIONS MENU
Use up and down buttons to move cursor on submenu at the end of page you move to next page. Menu
has 3 level structure, if user password is enabled some parameters requires user password.
Level 3 LCD panel options group
Panel language selection Page1
Button click ON/OFF Page1
LCD backlight brigthness Page2
Backlight delay Page2
Backlight dim.delay Page2
ENTER - EXIT Page3
OPTIONS /
LCD
OPTIONS
Page 1 (Level 3)
>LANGUAGE:ENGLISH
Left and right change panel language
(P3330)
CLICK: ON/OFF Left and right buton click sound ON/OFF
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
OPTIONS / LCD OPTIONS
Page 2 (Level 3)
>BACKLIGHT:XXXXXXXXX Left and right LCD backlight brightness adjust
BL DELAY:CLOSED Backlight delay
BL DIM:CLOSED Back light half option selection
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
OPTIONS / LCD OPTIONS
Page 3 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
Level 3 – Communication options
Remote control ON/OFF Page1
COM2 port function Page1
SNMP internal/external Page1
Relay 1 function selection Page2
Relay 2 function selection Page2
Relay 3 function selection Page2
Relay 4 function selection Page3
Relay 5 function selection Page3 Optional
Relay 6 function selection Page3 Optional
Relay 7 function selection Page4 Optional
Relay 8 function selection Page4 Optional
Relay 9 function selection Page4 Optional
Relay 10 function selection Page5 Optional
Relay 11 function selection Page5 Optional
Relay 12 function selection Page5 Optional
REPO input ON/OFF Page6
ENTER - EXIT Page7
