USER MANUAL
DS 300H Series � 3/3 � 30 kVA � UPS CONTROLLED UPS
3.2.9 USER PASSWORD
Some commands or some option selections are required user password, if menu position is required
password window comes to screen and UPS asks for user password. If you lost user password our service
personnel will recover your user password.
User password is 4 digits numbers, move cursor with left and right buttons, select digit and adjust the
number with up and down buttons. Do this for all digits and if password is typed completely press ENTER
buton. If the password is correct A43 USER LOGIN message will be shown on the LCD panel of the UPS.
-USER PASSWORD-
***************
* XXXX *
***************
Only authorized service personel has the useful password. Therefore it is hidden at above display.
3.3 Alarms and warning messages
The internal structure of the DS300H Series UPS is modular, these are:
-PFC Rectifier module
-Inverter module
-Front panel module
Module alarms and warnings are cathegorized according to modules at the front of the Alarm or warning
message module information is added:
-RXX Rectifier alarms and warnings
-AXX Inverter alarms and warnings
-LXX LCD front panel alarms and warnings
More then one alarm can be shown on the UPS front panel with time shared order. If 4 alarms are occurred
at the same time every 2 seconds 1 message will be showed, next 2 seconds 2.message will be showed
etc..
If A00 or R00 Alarm is shown on the LCD panel we understand that there is a system fault at the related
module. We saw the message in the A00 INV FAULT = XXXX or R00 PFC FAULT = XXXX format.
Numbers shown in X determines the status code which tells the problem to us. See status code table for
details of codes.
REC CODE = XXXX XXXX SYSTEM fault occured at the rectifer module
R00 REC FAULT = XXXX Fault Rectifier AC input voltage is high
CALL SERVICE !
R01 AC INPUT HIGH Alarm Rectifier AC input voltage is low
R02 LINE FAILURE Alarm Rectifier DC output voltage is high
R03 DC BUS HIGH Alarm The rectifier DC output voltage is high, rectifier stop
R05 FREQ TOLER Alarm Rectifier input frequcny out of tolerant
R06 OVERTEMPERATURE Alarm Rectifier heatsink temperature high
R07 BLACKOUT Alarm Short voltage blackout at rectifier AC input
R08 I/P OVERCURRENT Alarm Rectifier IGBT saturation alarm
R09 ROTATE PHASE Alarm Rectifier input phase sequency incorrect
R14 PFC MANUAL STOP Alarm Inverter module stopped rectifier
R15 DC LOW Alarm DC BUS voltage is lower then DC rectifier start voltage
R17 BATTERY TEST Warning Currently battery test is performing
R18 BOOST CHARGE Warning Currently rectifier is in boost charge mode
R19 AC HIGH Alarm AC Peak voltage is bigger then 20% of nominal range
R20 INPUT CB OPEN Warning Input CB is off
R21 PFC STOP Warning Currently Rectifier module stop
R22 POS CHG LIMIT Warning (+)Battery charge current limited
R23 NEG CHG LIMIT Warning (-)Battery charge current limited
