USER MANUAL
DS 300H Series � 3/3 � 30 kVA � UPS CONTROLLED UPS
20
MEASUREMENTS / INVERTER MENU (Level 2)
All inverter measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
INVERTER
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vinv: 221/222/223 V Phase to neutral measured AC Inverter output voltages
Finv: 50.0 Hz Measured Inverter output frequency
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
INVERTER
Page 2 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS / OUTPUT MENU (Level 2)
All UPS output measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
OUTPUT
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vout: 221/222/223 V Phase to neutral measured AC UPS output voltages
Iout: 00.0/00.0/00.0 A Measured AC RMS load currents
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
OUTPUT
Page 2 (Level 3)
P-P L13 L21 L32 Page header
Vout: 381/382/383 V Phase to phase measured AC UPS output voltages
Fout: 50.0 Hz Measured UPS output frequency
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
OUTPUT
Page 3 (Level 3)
Load 000/000/000 % Measured load percentage
KW 000.0/000.0/000.0 Measured output watt power
KVA 000.0/000.0/000.0 Measured output KVA power
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
OUTPUT
Page 4 (Level 3)
PF: ---- ---- ---- Load power factor
C.F: 0.0 / 0.0 / 0.0 Load crest factor
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
OUTPUT
Page 5 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
