No reading in display?
Send instrument for service.
Function test
for both pressure nipples
Warnings
Safety instructions
Initial operation
3
Capacity display
Voltage >7.2 V
Life of rechargeable battery: approx. 5 h
Life of battery: approx. 15 h
(at an ambient temperature of 20°C)
Flashing symbol, voltage: <7.2 V
Life of rechargeable battery: approx. 15 min.
Life of battery: approx. 45 min.
If the rechargeable battery voltage drops below
6.7 V automatic switch-off follows as protection
against total discharge.
Low Bat
++
Function check/Leak check
Prior the commencing any testing the complete
measuring system (intrument, probe and hoses) should
be checked for leaks
Temperature influence on the leak test
During any leak tests the ambient temperature must
remain constant to obtain valid data.
Instrument should only be used by trained personnel.
Always adhere to any system safety instructions and
never use the equipment in an explosive environment.
Under normal operating conditions gas will not escape
from the instrument when connected to the gas pipe /
system under test.
The instrument is not designed to operate while wet, or
in an environment of condensing humidity
The instrument should only be used in the conditions
and for the purposes for which it was constructed.
Please take particular note of the safety instructions
and the technical data.
The instrument should only be used in the operation and
measurement ranges specified in the technical data.
