CONTROL_STATUS: 0x0000
www.ti.com
38
SLUUBH1C–August 2016–Revised March 2018
Submit Documentation Feedback
Copyright © 2016–2018, Texas Instruments Incorporated
Data Commands
11.3.11 GAUGE_STOP: 0x0012
This command instructs the fuel gauge to exit ACTIVE mode and complete all tasks.
11.3.12 SEALED: 0x0020
This command instructs the fuel gauge to transition from UNSEALED state to SEALED state. The fuel
gauge should always be set to SEALED state for use in the customer’s end equipment.
11.3.13 CAL_ENABLE: 0x002D
This command instructs the fuel gauge to enable entry and exit to CALIBRATION mode.
11.3.14 LT_ENABLE: 0x002E
This command instructs the fuel gauge to enable Lifetime Data collection.
11.3.15 RESET: 0x0041
This command instructs the fuel gauge to perform a full reset. This command is only available when the
fuel gauge is UNSEALED.
11.3.16 NEW_BATTERY: 0xA613
This command instructs the fuel gauge to prepare itself for the next resistance update and EOS
determination to be with a new cell.
11.4 AccumulatedCapacity(): 0x02/0x05
This read-word 4-byte command returns the accumulated coulombs since the coulomb counter was
started. It provides an unsigned integer value with the range of 0 to 4.29E9 µAh. If the value reaches full,
it will hold at the full count and not roll over.
11.5 Temperature(): 0x06/0x07
This read-only command pair returns an unsigned integer value of the temperature, in units of 0.1°K,
measured by the device and has a range of 0 to 6553.5°K. The source of the measured temperature is
configured by the [TEMPS] bit in Operation Config A.
11.6 Voltage(): 0x08/0x09
This read-word command pair returns an unsigned integer value of the measured battery voltage in mV
with a range of 0 V to 65535 mV.
11.7 BatteryStatus() 0x0A
This read-only register provides indications on the status of the battery.
SBS
CMD.
NAME
ACCESS
PROTOCOL TYPE MIN MAX UNIT
SE US FA
0x0A BatteryAlert R R R Word HEX 0x00 0xff —
7 6 5 4 3 2 1 0
RSVD RSVD RSVD RSVD RSVD ALERT RSVD DSG
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
