Texas Instruments bq35100 User Manual

43
SLUUBH1C–August 2016–Revised March 2018
Submit Documentation Feedback
Copyright © 2016–2018, Texas Instruments Incorporated
Data Flash Summary
Chapter 13
SLUUBH1C–August 2016–Revised March 2018
Data Flash Summary
Table 13-1. Data Flash Table
Class Subclass Address Name Type Min Value Max Value Default Units
Calibration Data 0x4000 CC Gain F4 2.00E–02 10.00E+00 .04768 —
Calibration Data 0x4004 CC Delta F4
2.98262E+0
4
5.677445E
+06
5.677445
e4
—
Calibration Data 0x4008 CC Offset I2 –32767 32767 –1400 mA
Calibration Data 0x400A AD I Offset I2 –32767 32767 76 Num
Calibration Data 0x400C Board Offset I1 –128 127 0 Counts
Calibration Data 0x400D Int Temp Offset I1 –128 127 0 0.1°C
Calibration Data 0x400E Ext Temp Offset I1 –128 127 0 0.1°C
Calibration Data 0x400F Pack V Offset I1 –128 127 0 mV
Calibration Data 0x4010 VIN Gain U2 0 65535 29000 mV
Calibration Temp Model 0x4012 Int Coeff 1 I2 –32768 32767 0 Num
Calibration Temp Model 0x4014 Int Coeff 2 I2 –32768 32767 0 Num
Calibration Temp Model 0x4016 Int Coeff 3 I2 –32768 32767 –12324 Num
Calibration Temp Model 0x4018 Int Coeff 4 I2 –32768 32767 6131 0.1°K
Calibration Temp Model 0x401A Int Min AD I2 –32768 32767 0 —
Calibration Temp Model 0x401C Int Max Temp I2 –32768 32767 6131 0.1°K
Calibration Temp Model 0x401E Ext Coef 1 I2 –32768 32767 20982 Num
Calibration Temp Model 0x4020 Ext Coef 2 I2 –32768 32767 –13836 Num
Calibration Temp Model 0x4022 Ext Coef 3 I2 –32768 32767 5202 Num
Calibration Temp Model 0x4024 Ext Coef 4 I2 –32768 32767 2337 Num
Calibration Temp Model 0x4026 Ext rc0 I2 –32768 32767 12909 Counts
Calibration Temp Model 0x4028 Vcomp Coeff 1 I2 –32768 32767 0 Num
Calibration Temp Model 0x402A Vcomp Coeff 2 I2 –32768 32767 14902 Num
Calibration Temp Model 0x402C Vcomp Coeff 3 I2 –32768 32767 –623 Num
Calibration Temp Model 0x402E Vcomp Coeff 4 I2 –32768 32767 37 Num
Calibration Temp Model 0x4030 Vcomp Input Multiplier U1 0 255 48 Num
Calibration Temp Model 0x4031 Vcomp Output Divisor I2 –32768 32767 256 Num
Calibration Current 0x4033 Filter U1 0 255 239 Num
Configuration Registers 0x41B1 Operation Config A H1 0x00 0xFF 0x80 Hex
Configuration Registers 0x41B2 Alert Config H1 0x00 0xFF 0xF3 Hex
Configuration Registers 0x41B3 Clk Ctl Reg H1 0x00 0x0F 0x09 Hex
Configuration Registers 0x4254 Battery ID H1 0x0 0x03 0x00 Hex
Configuration Power 0x41B6 Flash Update OK Voltage I2 0 4200 2800 mV
Configuration Power 0x41B8 Offset Cal Inhibit Temp Low I2 –400 1200 50 0.1°C
Configuration Power 0x41BA Offset Cal Inhibit Temp High I2 –400 1200 450 0.1°C
Configuration Data 0x4060 Device Name S8 x x bq35100 —
Configuration Data 0x4068 Data Flash Version H2 0x0 0xFFFF 0xFFFF —
Configuration Data 0x41D4 Default Temperature I2 2732 3732 2982 0.1°K
Configuration Discharge 0x41D6 OT Dsg I2 0 1200 600 0.1°C
Configuration Discharge 0x41D8 OT Dsg Time U1 0 60 2 s
Configuration Discharge 0x41D9 OT Dsg Recovery I2 0 1200 550 0.1°C
Configuration Discharge 0x41DB
BatLow Voltage Set
Threshold
I2 0 32767 2700 mV
