Data Flash Summary
Table 13-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Configuration Discharge 0x41E0
Under Temperature Set
Threshold
I2 –400 250 50 0.1°C
Configuration Discharge 0x41E2 Under Temperature Set Time U1 0 60 2 s
Configuration Discharge 0x41E3 Under Temperature Clear I2 –400 250 100 0.1°C
Configuration Discharge 0x41E5 SOH Low I2 0 100 5 %
Configuration Integrity Data 0x4056 Static Chem DF Checksum H2 0x0 0x7FFF 0x58D2 Hex
Configuration Integrity Data 0x405C IF Checksum H4 0x0
0xFFFFFF
FF
0x4C0B3
D70
Hex
Configuration Integrity Data 0x4253 Reset Counter WD U1 0 255 0 Num
LTFlash Voltage 0x4240 Primary Max I2 0 32767 0 mV
LTFlash Voltage 0x4242 Primary Min I2 0 32767 32767 mV
LTFlash Current 0x4244 Max Discharge I2 –32768 0 –2000 mA
LTFlash Current 0x4246 Min Discharge I2 0 32767 0 mA
LTFlash Temperature 0x4248 Max Cell I2 –128 127 0 °C
LTFlash Temperature 0x424A Min Cell I2 –128 127 20 °C
LTFlash Temperature 0x424C Max Gauge I2 –128 127 0 °C
LTFlash Temperature 0x424E Min Gauge I2 –128 127 20 °C
System Data Manufacturer Data 0x4036 Manufacturer Info Block A01 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4037 Manufacturer Info Block A02 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4038 Manufacturer Info Block A03 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4039 Manufacturer Info Block A04 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403A Manufacturer Info Block A05 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403B Manufacturer Info Block A06 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403C Manufacturer Info Block A07 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403D Manufacturer Info Block A08 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403E Manufacturer Info Block A09 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x403F Manufacturer Info Block A10 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4040 Manufacturer Info Block A11 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4041 Manufacturer Info Block A12 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4042 Manufacturer Info Block A13 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4043 Manufacturer Info Block A14 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4044 Manufacturer Info Block A15 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4045 Manufacturer Info Block A16 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4046 Manufacturer Info Block A17 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4047 Manufacturer Info Block A18 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4048 Manufacturer Info Block A19 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4049 Manufacturer Info Block A20 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404A Manufacturer Info Block A21 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404B Manufacturer Info Block A22 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404C Manufacturer Info Block A23 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404D Manufacturer Info Block A24 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404E Manufacturer Info Block A25 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x404F Manufacturer Info Block A26 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4050 Manufacturer Info Block A27 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4051 Manufacturer Info Block A28 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4052 Manufacturer Info Block A29 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4053 Manufacturer Info Block A30 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4054 Manufacturer Info Block A31 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4055 Manufacturer Info Block A32 H1 0x0 0xFF 0x0 Hex
Gas Gauging Design 0x41FE Cell Design Capacity mAh I2 0 32767 2200 mAh
Gas Gauging Design 0x4202 Cell Design Voltage I2 0 32767 3700 mV
Gas Gauging Design 0x4204 Cell Terminate Voltage I2 0 32767 2000 mV
