Data Flash Summary
Table 13-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Gas Gauging Design 0x4206 Series Cell Count I1 1 8 1 Counts
Gas Gauging Design 0x4207 Max Load I2 0 32767 50 mA
Gas Gauging Design 0x4209 State of Health I1 0 100 100 %
Gas Gauging Design 0x420A State of Health Max Delta I1 0 100 2 %
Accum_Table Table0 0x4280 page active H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4281 Last Entry Code 0 H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4282 Last Entry Code 1 H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4283 Last Entry Code 2 H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4284 Last Entry Code 3 H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4285 Last Entry Code 4 H1 0x0 0xFF 0xFF —
Accum_Table Table0 0x4286 intPart 0 H2 0x0 0xFFFF 0x7FFF mA
Accum_Table Table0 0x4288 fractPart 0 H4 0x0
0xFFFFFF
FF
0x0 mA
Accum_Table Table0 0x428C intPart 1 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x428E fractPart 1 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x4292 intPart 2 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x4294 fractPart 2 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x4298 intPart 3 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x429A fractPart 3 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x429E intPart 4 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x42A0 fractPart 4 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x42A4 intPart 5 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x42A6 fractPart 5 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x42AA intPart 6 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x42AC fractPart 6 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x42B0 intPart 7 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x42B2 fractPart 7 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table0 0x42B6 intPart 8 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table0 0x42B8 fractPart 8 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42C0 page active H1 0x0 0xFF 0x55 —
Accum_Table Table1 0x42C1 Last Entry Code 0 H1 0x0 0xFF 0xFF —
Accum_Table Table1 0x42C2 Last Entry Code 1 H1 0x0 0xFF 0xFF —
Accum_Table Table1 0x42C3 Last Entry Code 2 H1 0x0 0xFF 0xFF —
Accum_Table Table1 0x42C4 Last Entry Code 3 H1 0x0 0xFF 0xFF —
Accum_Table Table1 0x42C5 Last Entry Code 4 H1 0x0 0xFF 0xFF —
Accum_Table Table1 0x42C6 intPart 0 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42C8 fractPart 0 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42CC intPart 1 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42CE fractPart 1 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42D2 intPart 2 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42D4 fractPart 2 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42D8 intPart 3 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42DA fractPart 3 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42DE intPart 4 H2 0x0 0xFFFF 0xFFFF mA
