Texas Instruments bq35100 User Manual

www.ti.com
46
SLUUBH1C–August 2016–Revised March 2018
Submit Documentation Feedback
Copyright © 2016–2018, Texas Instruments Incorporated
Data Flash Summary
Table 13-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Accum_Table Table1 0x42E0 fractPart 4 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42E4 intPart 5 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42E6 fractPart 5 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42EA intPart 6 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42EC fractPart 6 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42F0 intPart 7 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42F2 fractPart 7 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Accum_Table Table1 0x42F6 intPart 8 H2 0x0 0xFFFF 0xFFFF mA
Accum_Table Table1 0x42F8 fractPart 8 H4 0x0
0xFFFFFF
FF
0xFFFFF
FFF
mA
Ra Tables Ra0 Table 0x4175 Ra 0 I2 0 32767 1126
2
–10
Ω
Ra Tables Ra0 Table 0x4177 Ra 1 I2 0 32767 1197
2
–10
Ω
Ra Tables Ra0 Table 0x4179 Ra 2 I2 0 32767 1186
2
–10
Ω
Ra Tables Ra0 Table 0x417B Ra 3 I2 0 32767 1110
2
–10
Ω
Ra Tables Ra0 Table 0x417D Ra 4 I2 0 32767 1157
2
–10
Ω
Ra Tables Ra0 Table 0x417F Ra 5 I2 0 32767 1058
2
–10
Ω
Ra Tables Ra0 Table 0x4181 Ra 6 I2 0 32767 1121
2
–10
Ω
Ra Tables Ra0 Table 0x4183 Ra 7 I2 0 32767 1501
2
–10
Ω
Ra Tables Ra0 Table 0x4185 Ra 8 I2 0 32767 1646
2
–10
Ω
Ra Tables Ra0 Table 0x4187 Ra 9 I2 0 32767 1749
2
–10
Ω
Ra Tables Ra0 Table 0x4189 Ra 10 I2 0 32767 2898
2
–10
Ω
Ra Tables Ra0 Table 0x418B Ra 11 I2 0 32767 5888
2
–10
Ω
Ra Tables Ra0 Table 0x418D Ra 12 I2 0 32767 13825
2
–10
Ω
Ra Tables Ra0 Table 0x418F Ra 13 I2 0 32767 18933
2
–10
Ω
Ra Tables Ra0 Table 0x4191 Ra 14 I2 0 26430 26303
2
–10
Ω
EOSData Values 0x4255 R Data Seconds I2 0 5000 15 Num
EOSData Values 0x4257 R Table Scale I2 –1 –1 –1 Num
EOSData Values 0x4259 New Batt R Scale Delay U1 0 255 2 Num
EOSData Values 0x425A R Table Scale Update Flag H1 0x00 0xFF 0xFF Hex
EOSData Values 0x425B R Short Trend Filter U1 1 255 251 Num
EOSData Values 0x425C R Long Trend Filter U1 1 255 253 Num
EOSData Values 0x425D EOS Trend Detection % U1 1 100 20 Num
EOSData Values 0x425E
EOS Detection Pulse Count
Thrshd
U2 1 20000 120 Num
EOSData Values 0x4260 Short Trend Average U4 0 8355712 0 Num
EOSData Values 0x4264 Long Trend Average U4 0 8355712 0 Num
EOSData Values 0x4268
EOS Trend Detection Pulse
Counts
U2 0 20000 0 Num
EOSData Values 0x426A EOS Not Detected Flag H1 0x0 0xFF 0xFF Hex
EOSData Values 0x426B
EOS SOH smooth Start
Voltage
I2 1 32767 2800 mV
EOSData Values 0x426D EOS SOH Smoothing Margin U1 1 255 128 Num
EOSData Values 0x426E EOS Relax V Hi Max Counts U1 1 255 10 Num
Security Codes 0x41BC Authen Key3 MSB H2 0x0000 0xFFFF 0x0123 Hex
Security Codes 0x41BE Authen Key3 LSB H2 0x0000 0xFFFF 0x4567 Hex
Security Codes 0x41C0 Authen Key2 MSB H2 0x0000 0xFFFF 0x89AB Hex
Security Codes 0x41C2 Authen Key2 LSB H2 0x0000 0xFFFF 0xCDEF Hex
Security Codes 0x41C4 Authen Key1 MSB H2 0x0000 0xFFFF 0xFEDC Hex
Security Codes 0x41C6 Authen Key1 LSB H2 0x0000 0xFFFF 0xBA98 Hex
