5
SLUUBH1C–August 2016–Revised March 2018
Submit Documentation Feedback
Copyright © 2016–2018, Texas Instruments Incorporated
Read This First
Preface
SLUUBH1C–August 2016–Revised March 2018
Read This First
About This Manual
This technical reference manual (TRM) discusses the modules and peripherals of the bq35100 device,
and how each is used to build a complete battery fuel gauge and end-of-service monitor. Content in this
TRM complements, not supersedes, information in the bq35100 Lithium Primary Battery Fuel Gauge and
End-Of-Service Monitor Data Sheet (SLUSCM6).
Notational Conventions
This document uses the following conventions:
• Hexadecimal numbers may be shown with the suffix h or the prefix 0x. For example, the following
number is 40 hexadecimal (decimal 64): 40h or 0x40.
• Registers in this document are shown in figures and described in tables.
– Each register figure shows a rectangle divided into fields that represent the fields of the register.
Each field is labeled with its bit name, its beginning and ending bit numbers above, and its
read/write properties with default reset value below. A legend explains the notation used for the
properties.
– Reserved bits in a register figure can have one of multiple meanings:
• Not implemented on the device,
• Reserved for future device expansion,
• Reserved for TI testing,
• Reserved configurations of the device that are not supported.
– Writing non-default values to the Reserved bits could cause unexpected behavior and should be
avoided.
Formatting in This Document
The following formatting convention is used in this document:
• SBS Commands: italic with parenthesis and no breaking spaces; for example, RemainingCapacity()
• Data Flash: italic, bold, and breaking spaces; for example, Design Capacity
• Data Flash Bits: italic and bold; for example, [LED1]
• Register Bits and Flags: italic and brackets; for example, [TDA]
• Modes and States: ALL CAPITALS; for example, UNSEALED
Trademarks
E2E is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners.
Related Documentation From Texas Instruments
See the bq35100 Lithium Primary Battery Fuel Gauge and End-Of-Service Monitor Data Sheet
(SLUSCM6).
For product information, visit the Texas Instruments website at http://www.ti.com/product/bq35100.
