Bill of Materials
Appendix B
SNAU210–March 2017
Bill of Materials
Table 3. Bill of Materials
DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER QUANTITY
!PCB Printed-Circuit Board Any SV601308 1
C1, C3, C9, C14,
C15, C17, C30
CAP, CERM, 0.1 µF, 16 V, ±5%,
X7R, 0603
AVX 0603YC104JAT2A 7
C1_LF
CAP, CERM, 390 pF, 50 V,
±5%, C0G/NP0, 0603
Kemet C0603C391J5GACTU 1
C2, C4, C8, C16
CAP, CERM, 10 µF, 10 V,
±10%, X5R, 0805
Kemet C0805C106K8PACTU 4
C2_LF
CAP, CERM, 0.068 µF, 50 V,
±10%, X7R, 0603
MuRata GRM188R71H683KA93D 1
C4_LF
CAP, CERM, 1800 pF, 50 V,
±5%, C0G/NP0, 0603
MuRata GRM1885C1H182JA01D 1
C5, C6, C7, C10,
C11, C12
CAP, CERM, 0.01 µF, 16 V,
±10%, X7R, 0402
AT Ceramics 520L103KT16T 6
C13, C18, C23,
C24, C26, C27,
C28, C29
CAP, CERM, 1 µF, 16 V, ±10%,
X7R, 0603
TDK C1608X7R1C105K080AC 8
C19, C20, C21,
C22, C25
CAP, CERM, 10 µF, 10 V,
±20%, X5R, 0603
TDK C1608X5R1A106M080AC 5
CE_TP, CSB_TP,
GND_TP,
MUXout_TP,
RampCLK_TP,
RampDIR_TP,
SCK_TP, SDI_TP,
SYNC_TP,
SysRefReq_TP,
Vcc_TP,
VccRF_TP,
Vtune_TP
Test Point, Compact, White, TH Keystone 5007 13
Cin_0
CAP, CERM, 10 µF, 25 V,
±10%, X5R, 0805
MuRata GRM219R61E106KA12D 1
Cout0
CAP, CERM, 22 µF, 16 V,
±10%, X5R, 0805
TDK C2012X5R1C226K125AC 1
Css
CAP, CERM, 3300 pF, 50 V,
±5%, C0G/NP0, 0603
MuRata GRM1885C1H332JA01D 1
D1 LED, Green, SMD Lite-On LTST-C190GKT 1
L1, L2
Inductor, Multilayer, Air Core, 18
nH, 0.3 A, 0.36 Ω, SMD
MuRata LQG15HS18NJ02D 2
L1_TPS
Inductor, Shielded, Composite,
2.2 µH, 3.7 A, 0.02 Ω, SMD
Coilcraft XFL4020-222MEB 1
LBL1
Thermal Transfer Printable
Labels, 0.650" W x 0.200" H -
10,000 per roll
Brady THT-14-423-10 1
MUXout_SW
Switch, SPST, Slide, Off-On, 2
Pos, 0.1 A, 20 V, SMD
CTS Electrocomponents 219-2MST 1
