eCAN Boot Function
Table 2-9. eCAN 8-Bit Data Stream
AA 08 Keyvalue: 0x08AA
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
00 00 Part of 8 reserved words stream
bb aa Most significant (MSW) part of 32-bit address (aabb)
dd cc Least significant (LSW) part of 32-bit address (ccdd) -
Final entry-point address = 0xaabbccdd
nn mm Length of first section (mmnn)
ff ee MSW part of 32-bit address (eeff)
hh hh LSW part of 32-bit address (gghh) - Starting address of first section = 0xeeffgghh
xx xx First word of first section
xx xx Second word of first section
... ...
... ...
... ...
xx xx Last word of first section
nn mm Length of second section (mmnn)
ff ee MSW part of 32-bit address (eeff)
hh gg LSW part of 32-bit address (gghh) - Starting address of second section = 0xeeffgghh
xx xx First word of second section
xx xx Second word of second section
... ...
... ...
xx xx Last word of second section
(more sections if needed)
00 00 Section length of zero for next section indicates end of data.
Bootloader Features46 SPRU722C – November 2004 – Revised October 2006
