www.ti.com
Bootloader Code Listing (V3.0)
// Initialize I2C in master transmitter mode
I2caRegs.I2CSAR = 0x0050; // Slave address - EEPROM control code
I2caRegs.I2CPSC.all = 0x0; // I2C clock should be between 7Mhz-12Mhz
I2caRegs.I2CCLKL = 0x0035; // Prescalers set for 100kHz bit rate
I2caRegs.I2CCLKH = 0x0035; // at a 12Mhz I2C clock
I2caRegs.I2CMDR.all = 0x0620; // Master transmitter
// Take I2C out of reset
// Stop when suspended
I2caRegs.I2CFFTX.all = 0x6000; // Enable FIFO mode and TXFIFO
I2caRegs.I2CFFRX.all = 0x2000; // Enable RXFIFO
return;
}
//#################################################
// Uint16 I2C_CheckKeyVal(void)
//-----------------------------------------------
// This routine sets up the starting address in the
// EEPROM by writing two bytes (0x0000) via the
// I2C-A port to slave address 0x50. Without
// sending a stop bit, the communication is then
// restarted and two bytes are read from the EEPROM.
// If these two bytes read do not equal 0x08AA
// (little endian), an error is returned.
//-----------------------------------------------
inline Uint16 I2C_CheckKeyVal(void)
{
// To read a word from the EEPROM, an address must be given first in
// master transmitter mode. Then a restart is performed and data can
// be read back in master receiver mode.
I2caRegs.I2CCNT = 0x02; // Setup how many bytes to send
I2caRegs.I2CDXR = 0x00; // Configure fifo data for byte
I2caRegs.I2CDXR = 0x00; // address of 0x0000
I2caRegs.I2CMDR.all = 0x2620; // Send data to setup EEPROM address
while (I2caRegs.I2CSTR.bit.ARDY == 0) // Wait until communication
{ // complete and registers ready
}
if (I2caRegs.I2CSTR.bit.NACK == 1) // Set stop bit & return error if
{ // NACK received
I2caRegs.I2CMDR.bit.STP = 1;
return ERROR;
}
// Check to make sure key value received is correct
if (I2C_GetWord() != 0x08AA) {return ERROR;}
return NO_ERROR;
}
//#################################################
// void I2C_ReservedFn(void)
//-------------------------------------------------
// This function reads 8 reserved words in the header.
// 1st word - parameters for I2CPSC register
// 2nd word - parameters for I2CCLKH register
// 3rd word - parameters for I2CCLKL register
//
80 Bootloader Code Overview SPRU722C November 2004 Revised October 2006
Submit Documentation Feedback
