Page #26 background imageLoading...
Page #26 background image
XDS110 Adaptors
www.ti.com
26
SPRUI94–January 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
XDS110 Debug Probe
Table 5. Auxiliary Breakout Board Signal Mapping
XDS110 AUX Signal Break Board Interface Pins
TGTSUPPLYIN 1
TGTSUPPLYOUT 2
TGTVDD(Sense) 3
GND 4,5,10
GPIOOUT0 6
GPIOOUT1 7
GPIOIN0 8
GPIOIN1 9
UARTTX 11
UARTRX 12
