www.ti.com
Overview
5
SPRUI94–January 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
XDS110 Debug Probe
• TI platforms, devices, and ISAs supported
– MSP432 MCUs
– CC26xx/13xx wireless MCUs
– CC32xx/31xx Wi-Fi MCUs
– Hercules and Conqueror safety MCUs
– Sitara
– Stellaris MCUs
– C2000 MCUs
– C66xx
– C64x+
– C674x
– C55xx
– C54xx
– DaVinci
– OMAP
1.3 XDS110 Performance
The XDS110 debug probe has much higher debug performance than XDS100v2. Depending on the target
device, host environment, and configuration, the XDS110 performs 3× to 5× better than the existing
XDS100v2 debug probe.
Example: BeagleBone Cortex A8 (Code Composer 6.2 setup on Windows 7 PC):
• XDS100v2 RAM download = 21 kbps
• XDS110 RAM download = 110 kbps
NOTE: Some TI scan-based debug platforms, such as the C6000, C5500, and C2000 DSP families,
will not see the same magnitude of performance improvements.
1.4 XDS110 Probe Overview
Figure 1 shows a high-level diagram of the major functional areas and interfaces of the XDS110 probe.
Details of these are contained in Section 3.
