Installation
INS 034-9 9
2.4.1.1 PCB Terminals and Fuses
Terminal Description Note
AC (2) Transformer AC in NOT for mains supply
BATT- Standby Battery negative
BATT+ Standby Battery positive
SSAB Strobe switched negative
D SAB negative Supply
C SAB negative Tamper return
B SAB Bell switched negative
A SAB positive Supply
L/S (2) Loudspeaker
AUX- Auxiliary Supply negative use for detectors
AUX+ Auxiliary Supply positive use for detectors
SW+ Switched Positive output
TAMP Global Tamper loop
Z1 - Z8 Zone loops
T Keypad data
R Keypad data
AUX- Auxiliary Supply negative use for RKP(s)
AUX+ Auxiliary Supply positive use for RKP(s)
1)
A spare mains fuse is supplied in a clip adjacent to the mains terminal block.
2)
Spare PCB fuses are supplied in a press-seal bag.
Fuse Description Rating
F1 Battery fuse F1A, 250V, 20mm
F2 Bell & Strobe fuse F1A, 250V, 20mm
F3 L/S & Detector Auxiliary fuse F500mA, 250V, 20mm
F4 RKP Auxiliary fuse F500mA, 250V, 20mm
F5 Power Supply Output fuse F1.6A, 250V, 20mm
1)
When replacing a fuse always observe the specified rating and type - failure to do so
is dangerous and will invalidate the warranty. Fuses should comply with IEC 127.
2)
The press-seal bag must NOT be stored inside the panel.
2.4.2
Wiring the External Sounder and Strobe
Always consult the manufacturer's connection instructions. The external sounder
and strobe are connected to the five terminals labelled SAB on the control panel
as follows:
Terminal Description
A Permanent Positive Supply (+12V)
B Switched Negative to Activate Sounder
C Negative Tamper Return
D Permanent Negative Supply (0V)
S Switched Negative to Activate Strobe
