Safety - 1 - 10 CD397-Oper
June 2019 (Rev C)
Mobile Belt Loader Model 660-28 Safety
Operation Manual Section 1
Perform the following steps when the engine is inoperable, but still has electrical power. When there is not
enough electrical power to engage the emergency steering pump, perform the following steps:
1. Use a tow bar to attach the disabled unit and an operational tow tractor.
2. Release the park brake.
3. Tow unit as described in 1.4.1.5 Belt Loader Towing Instructions.
4. Once towing destination is reached, place transmission of the towing vehicle in neutral, apply the
park brake and turn the ignition key to the OFF position.
5. Chock wheels of the disabled unit.
6. Disconnect the vehicles by removing the tow bar.
1.4.1.5BeltLoaderTowingInstructions
The Belt Loader should be moved with a suitable tow truck or on a flat bed tow truck. If this is not practical,
the Belt Loader can be towed with all four wheels on the ground. In this situation, extreme diligence is
required.
1. Connect the tow straps to the D-rings located under the front bumper. The D-rings should be
marked with decals labeled TOW.
2. Put the transmission in Neutral.
CAUTION:
Towing speed must NOT exceed 3 mph (5 km/h). Do NOT tow the disabled unit more
than 6 miles (10 km).
The disabled unit will be difficult to steer as there is no hydraulic pressure available.
NOTE:
Steer the disabled unit to follow the towing unit.
CAUTION:
Do not tow the Belt Loader if it has experienced a hydraulic failure as the unit may not
be steerable.
The maximum tow distance with the drive shaft installed is 1 mile (1.6 km) at a speed
of no more than 5 mph (8 km/h). If the required towing distance is more than 1 mile
(1.6 km), the drive shaft must be removed from the Belt Loader to avoid transmission
damage.
The maximum towing speed is 3 mph (4.8 km/h) with inoperable engine and 6 mph
(9.65 km/h) with operable engine.
WARNING:
FAILURE TO USE PROPER TOWING GEAR CAN CAUSE SERIOUS INJURY OR
DEATH.
CAUTION:
Do not allow the Belt Loader to be pushed by other equipment.
Tow only with suitably sized tow straps rated for the weight of the Belt Loader.
Property of American Airlines
