CD397-Oper Operation - 3 - 1
August 2018 (Rev B)
Operation Mobile Belt Loader Model 660-28
Section 3 Operation Manual
Section3:SpecificationsandCapabilities
3.1UnitDimensions
3.2Con ve yorDimensions
3.2.1ConveyorPositions
TableOperation-3-1:DimensionsandMeasurements
Dimension Measurement
Length 300 in. (762 cm)
Width (excluding side bumpers) 78 in. (198.1 cm)
Height 59 in. (149.9 cm)
Wheelbase 110 in. (279.4 cm)
Ground Clearance 7.5 in. (19.05 cm)
Turning Radius (measured to the outside from wheel) 27 ft. (8.2 m)
Gross Vehicle Weight with Cab 7,200 lb (3266 kg)
Gross Vehicle Weight without Cab 7,000 lb (3175 kg)
TableOperation-3-2:ConveyorDimensions
ConveyorAttitude Measurement
Conveyor Length (less front bumper) 294 in (746.7 cm)
Standard Conveyor Width (less side rails) 34 in (86.4 cm)
Narrow Conveyor Width (less side rails) 31.5 in (80 cm)
Belt Width 24 in (61 cm)
TableOperation-3-3:ConveyorPositions
Conve yorAttitude Front Rear Lateral Angle
Front Up, Rear Down 170 in. (431.8 cm) 13 in. (33.02 cm) 224 in. (569 cm) 35°
Front Up, Rear Up 168 in. (426.72 cm) 37 in. (93.98 cm) 257 in. (653 cm) 27°
Front Down, Rear Down 40 in. (101.6 cm) 36 in. (91.44 cm) 294 in. (747 cm) 1°
Front Down, Rear Up 31 in. (78.74 cm) 61 in. (154.94 cm) 285 in. (724 cm) -6°
