Mobile Belt Loader Model 660-28 Operation
Operation Manual Section 1
The operator indicator light is located on the left hand side of the conveyor near the front bumper. It is
installed on the left hand sensor pod with a guard over the top of the light.
FigureOperation-1-4:OperatorIndicatorLight
The supervisor light operation mirrors the operator light and serves to alert management or anone else
around the belt loader as to the status of the Smart Sense system. The standard location for the supervisor
light is on the left rear corner of the conveyor.
FigureOperation-1-5:SupervisorIndicatorLight
1.3.12.6SeatSwitch
