Operation - 3 - 4 CD397-Oper
August 2018 (Rev B)
Mobile Belt Loader Model 660-28 Operation
Operation Manual Section 3
3.4Performance
3.5CompatibleAircraft
Table Operation-3-6, “Aircraft Compatibility,” provides a list by aircraft manufacturers and models showing
the front and rear cargo door heights with an additional 30 in. (76.2 cm) conveyor height above the door sill
to allow for ease of loading and unloading of cargo. The rear of the conveyor is set at 30 in. (76.2 cm)
above ground level.
The listed aircraft are compatible with the Mobile Belt Loader 660-28. The height measurements are from
the IATA Airport Handling Manual (AHM) 904 “Aircraft Doors, Servicing Points and System Requirements
for the Use of Ground Support Equipment.”
Wheels and Tires 8.00 x 16.5, 6-ply tubeless on 16.5 x 6.0 G wheels
Standard Operation Temperature Minimum: -25° F (-31° C); Maximum: 125° F (52° C)
NOTE:
Please contact Tug customer care for operating procedures in colder environments.
TableOperation-3-5:Performance
Unit Specification
Unit Maximum Speed 25 mph (43 kph)
Conveyor Capacity (up to 15°
elevation)
2000 lb (907 kg)
Conveyor Belt Speed 45 to 90 ft/min (14 to 27 m/min)
Aircraft Compatibility Will service aircraft with door sills height from 40 to 170 in
(101 to 431 cm)
TableOperation-3-6:AircraftCompatibility
AircraftType FrontDoor RearDoor
Airbus A300 B2 320-B2/C4 137.5 in.(349.25 cm) 152.04 in. (386.18 cm)
Airbus A300 F4-600 134.52 in. (341.68 cm) 155.16 in. (394.11 cm)
Airbus A310-200/200C 133.32 in. (338.63 cm) 136.32 in. (346.25 cm)
Airbus A318 111.6 in. (283.46 cm) 121.2 in. (307.85 cm)
Airbus A319 103.08 in. (261.82 cm) 118.68 in. (301.45 cm)
Airbus A320 110.88 in. (281.64 cm) 113.28 in. (287.73 cm)
Airbus A321 111.6 in. (283.46 cm) 118.8 in. (307.75 cm)
Airbus A330-200F 152.4 in. (387.096cm) 168.6 in. (428.24 cm)
TableOperation-3-4:SpecificationData(Continued)
Item Specification
Property of American Airlines
