CD397-Oper Operation - 2 - 3
June 2019 (Rev C)
Operation Mobile Belt Loader Model 660-28
Section 2 Operation Manual
TableOperation-2-1:OperatorCompartment
No. Component Description
1 Instrument/Dash Panel Contains the control switches
2 Turn Signal
The turn signal lever is used when making right or left turns.
To indicate a right turn, push the signal control lever up or to
indicate a left turn, push the lever down.
3 Steering Wheel
Use the steering wheel to make turns. Rotate clockwise to
turn right or rotate counter clockwise to turn left.
4 Shifter
Plate in “F” to move forward, “N” to Neutral and “R” to move
reverse.
5 Park Brake Lever Operates the hydraulic brake on the front and rear wheels.
6 Rear Cylinder Control Operates the rear of conveyor belt.
7 Front Cylinder Control Operates the front of conveyor belt.
8 Accelerator Pedal Control the unit speed.
9 Brake Pedal
To decrease speed or stop the vehicle, depress the brake
pedal.
