GB-11
EC
Hydro
Midsize
FIXED CUTTERDECK ATTACHMENT
1. Remove the cutterdeck from the crate.
2. Unbolt the caster wheels and the shipping
brackets from the crate.
3. Remove the shipping bracket from the caster
wheel by loosening the caster bolt and sliding
the shipping bracket off and retighten caster bolt.
4. Remove quick pin and remove the appropriate
number of spacers for the desired height of cut.
See height of cut chart below.
NOTE: Height of cut chart is also located on
bottom of belt cover or in the Operation & Safety
Manual.
5. Repeat for other caster wheel assembly.
ASSEMBLY/SET-UP INSTRUCTIONS
